Chuck Metals stands out as a trusted manufacturer and supplier of Duplex Steel Round Bars in Singapore, meeting the industrial needs of Pulau Ujong with precision-engineered, corrosion-resistant solutions. These round bars are celebrated for their remarkable strength, outstanding corrosion resistance, and impressive toughness, particularly in challenging environments. Crafted to comply with global standards like ASTM A276, ASTM A479, and ASME SA276, our duplex steel round bars are perfect for both structural and machining applications.
Made up of roughly 22–25% chromium, 4.5–6.5% nickel, 2.5–3.5% molybdenum, and nitrogen, these bars boast tensile strengths between 620 and 900 MPa and yield strengths from 450 to 620 MPa. The unique ferritic-austenitic dual-phase microstructure significantly boosts resistance to stress corrosion cracking, pitting, crevice corrosion, and fatigue, even in chloride-rich or acidic environments, all while ensuring good weldability and machinability.
Standards : EN, DIN, JIS, ASTM, BS, ASME, AISI
Size : 10 mm To 100 mm Dia in
Length : 100 mm TO 6000 mm Length.
Specifications : ASTM A276, A479 / ASME SA276, SA479
Form : Round
Finish : Bright, Polish & Black
Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
S31803 | 0.030 max | 2.00 max | 1.00 max | 0.030 max | 0.020 max | 22.0 – 23.0 | 3.0 – 3.5 | 4.50 – 6.50 | 0.14 – 0.20 | 63.72 min |
S32205 | 0.030 max | 2.00 max | 1.00 max | 0.030 max | 0.020 max | 21.0 – 23.0 | 2.50 – 3.50 | 4.50 – 6.50 | 0.8 – 0.20 | 63.54 min |
| S31803 / S32205 | Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 7.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80000 , MPa – 550 | Psi – 116000 , MPa – 800 | 15 % |
To select the right Duplex Steel Round Bars, consider factors like corrosion resistance, mechanical strength, temperature conditions, and the specific industry requirements. Consult material specifications and expert advice for optimal selection.
Common grades of Duplex Steel used in round bar manufacturing include 2205 (F51), 2507 (F53), and 2304, each offering varying levels of corrosion resistance, strength, and weldability for specific applications.
Yes, Duplex Steel Round Bars are fully recyclable. Their high-quality composition allows them to be reused in various industries without compromising performance or structural integrity.
Duplex steel round bars find extensive use in sectors like oil & gas, chemical processing, marine engineering, power generation, and pulp and paper industries. They are commonly utilized in applications such as shafts, valves, pump components, fasteners, and load-bearing structures where a blend of strength, corrosion resistance, and dimensional stability is essential. These bars deliver long-lasting performance in aggressive settings, making them a smart and reliable material choice.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
