Today, a growing number of industries are seeking high-quality Nickel Alloy Round Bars to meet their specific needs. Chuck Metals, based in Singapore, Singapore, is dedicated to meeting this demand by offering superior Nickel Alloy Round Bars that stand out in performance and reliability. With a focus on quality and precision. We put in continuous effort to provide products that exceed customer expectations. Our Nickel Alloy Round Bars are known for their exceptional corrosion resistance, strength, and suitability for demanding applications across industries like aerospace, marine, and chemical processing. Whether you require customized sizes or specialized grades, we ensure each product meets the highest standards of excellence.
Ni Alloy Round Bars are standard-sized round bars made from nickel-based alloys, which give them characteristic properties of enormous strength, corrosion resistance, and high-temperature endurance. These bars find their application in aerospace, chemical processing, marine, etc., similar industries, where the applications are usually made for harsh environments. Some common compositions of Nickel Alloy Round Bars would include a large percentage (usually around 50-70%) of nickel alloyed with other elements, including chromium, molybdenum, iron, and sometimes even copper, aluminum, or titanium, as such elements tend to enhance the overall oxidation, pitting, or stress corrosion resistance of the nickel alloys. Such characteristics make these bars suitable for applications with extreme performance requirements.
| Grade | Nickel Alloy – Pure Nickel |
|---|---|
| Specification | Nickel Bar Cold Finished : B160, SB160 400: B164, SB164, QQ-N-281 405: B164, SB164, QQ-N-281, ASTM B160 |
| Standard | ASTM, ASME, API, GB, AISI, DIN, EN, SUS, UNS |
| Round bar size | Diameter: 3-~800mm |
| Round Bar Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Round Bar Surface | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| Condition | Hardened & tempered, annealed |
| Technique | Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Processing | Bar cutting to 650mm |
| Ni | Fe | C | Mn | Si | Cu | Mg | Ti | S |
|---|---|---|---|---|---|---|---|---|
| 99.0 Min | 0.4 Max | 0.02 Max | 0.35 Max | 0.2 Max | 0.25 Max | 0.15 Max | 0.1 Max | 0.01 Max |
| 99.0 Min | 0.4 Max | 0.15 Max | 0.35 Max | 0.1 Max | 0.25 Max | – | – | 0.01 Max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.9 G/Cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
| SIZE IN INCHES | LENGTH IN INCHES | WGHT./FT. |
|---|---|---|
| .500 | 120/216 | 0.749 |
| .750 | 120/216 | 1.686 |
| .875 | 120/216 | 2.295 |
| 1.250 | 120/216 | 4.683 |
| 1.375 | 120/216 | 5.666 |
| 1.500 | 120/316 | 6.743 |
| 1.750 | 120/216 | 9.179 |
| 2.000 | 120/216 | 11.988 |
| 2.250 | 120/216 | 15.173 |
| 2.500 | 120/216 | 18.732 |
| 2.750 | 120/216 | 22.665 |
| 2.875 | 120/216 | 24.773 |
| 3.000 | 120/216 | 26.974 |
| 3.250 | 120/216 | 31.657 |
| 3.500 | 120/216 | 36.714 |
Nickel Alloy Round Bars are used globally as a super-strength round bar or super corrosion-resistant round bar. Exceptions involve their use as turbine blades or exhaust systems in the aerospace industry. In chemical processing, they could be reactors, heat exchangers, and pipes used in aggressive chemicals. The marine world recognizes this resource in shipbuilding, underwater equipment, and offshore platforms, especially in applications where resistance to seawater corrosion is essential. They are further used in the power and automotive industries and even in oil and gas for valves, pumps, and high-performance components.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
