Chuck Metals is a reputable manufacturer and supplier of Nickel Alloy Bright Bars based in Singapore, Pulau Ujong. They offer top-notch nickel-based bars designed for applications that demand exceptional corrosion resistance, thermal stability, and mechanical strength. These bright bars undergo a cold-finishing process to ensure a smooth surface, precise dimensional tolerances, and improved mechanical properties. Chuck Metals boasts a diverse selection of nickel alloy grades, including Nickel 200, 201, 625, 718, and more, all customized to meet the rigorous demands of industries like marine, chemical processing, aerospace, oil & gas, and electronics. With their commitment to precision manufacturing and reliable service, Chuck Metals has become a go-to source for nickel alloy bright bars.
Nickel Alloy Bright Bars are mainly made from high-purity nickel (with some grades reaching up to 99.6%) and may also contain elements like chromium, molybdenum, copper, and iron, depending on the specific alloy. These bars are known for their outstanding resistance to oxidation, acids, alkalis, and high-temperature conditions. While mechanical properties can vary by grade, they typically feature tensile strength ranging from 400 to 1000 MPa, along with excellent ductility, thermal conductivity, and workability. The bright finish not only enhances their appearance but also makes them perfect for applications that require precise tolerances and high surface quality.
| Grade | Nickel Alloy – Pure Nickel |
|---|---|
| Specification | Nickel Bar Cold Finished : B160, SB160 400: B164, SB164, QQ-N-281 405: B164, SB164, QQ-N-281, ASTM B160 |
| Standard | ASTM, ASME, API, GB, AISI, DIN, EN, SUS, UNS |
| Round bar size | Diameter: 3-~800mm |
| Round Bar Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Round Bar Surface | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| Condition | Hardened & tempered, annealed |
| Technique | Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Processing | Bar cutting to 650mm |
| Ni | Fe | C | Mn | Si | Cu | Mg | Ti | S |
|---|---|---|---|---|---|---|---|---|
| 99.0 Min | 0.4 Max | 0.02 Max | 0.35 Max | 0.2 Max | 0.25 Max | 0.15 Max | 0.1 Max | 0.01 Max |
| 99.0 Min | 0.4 Max | 0.15 Max | 0.35 Max | 0.1 Max | 0.25 Max | – | – | 0.01 Max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.9 G/Cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
| SIZE IN INCHES | LENGTH IN INCHES | WGHT./FT. |
|---|---|---|
| .500 | 120/216 | 0.749 |
| .750 | 120/216 | 1.686 |
| .875 | 120/216 | 2.295 |
| 1.250 | 120/216 | 4.683 |
| 1.375 | 120/216 | 5.666 |
| 1.500 | 120/316 | 6.743 |
| 1.750 | 120/216 | 9.179 |
| 2.000 | 120/216 | 11.988 |
| 2.250 | 120/216 | 15.173 |
| 2.500 | 120/216 | 18.732 |
| 2.750 | 120/216 | 22.665 |
| 2.875 | 120/216 | 24.773 |
| 3.000 | 120/216 | 26.974 |
| 3.250 | 120/216 | 31.657 |
| 3.500 | 120/216 | 36.714 |
Discover the benefits of Nickel Alloy Bright Bars, including high strength, corrosion resistance, durability, and versatility for industrial applications.
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@chuckmetals.com
These Nickel Alloy Bright Bars find extensive use in environments where corrosion and heat resistance are crucial. They are commonly used in fasteners, shafts, valves, heat exchangers, marine hardware, medical devices, and high-performance components in power generation and aerospace systems. Thanks to their smooth finish, impressive mechanical properties, and durability, they are ideal for precision machining, fabrication, and assembly. Whether facing harsh chemical conditions or extreme temperatures, Nickel Alloy Bright Bars consistently deliver reliable performance and a long service life in critical engineering applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
