Chuck Metals stands out as a top-notch manufacturer and supplier of high-quality Titanium Square Bars right in Singapore, specifically on Pulau Ujong. With years of experience under their belt, this company has built a reputation for delivering precision-engineered titanium products that adhere to international quality standards. Catering to a diverse array of industries, Chuck Metals guarantees that each Titanium Square Bar boasts exceptional strength, corrosion resistance, and durability. Their dedication to innovation and customer satisfaction has made them a trusted name in Singapore’s metal supply scene. Whether you need them for industrial or commercial purposes, Chuck Metals offers customized solutions to fit various project needs.
Typically, Titanium Square Bars are made from commercially pure titanium or titanium alloys like Grade 2 or Grade 5 (Ti-6Al-4V). The chemical makeup includes titanium (90–99%), along with trace amounts of aluminum, vanadium, oxygen, iron, and carbon, depending on the specific grade. These bars are known for their impressive strength-to-weight ratio, high tensile strength (up to 1380 MPa for Grade 5), and remarkable corrosion resistance, particularly in marine and chemical settings. They also exhibit excellent fatigue resistance, low thermal expansion, and high melting points, making them perfect for demanding applications in extreme conditions.
| Standard | ASTM B348/ASME SB348, ASTMF67, ASTM F136, ISO-5832-2(3), AMS4928, MIL-T-9047G, JIS etc |
| Grade | TA1-TA4, TA7-TA10, TA15-TA18, GR1-GR5, GR6,GR7, GR9, GR11, GR12, TI-6AL-4V, TI-6AL-4VELI,GR23 |
| Diameter | 5-350mm |
| Length | Max6000mm |
| Technique | Forging ,Machining |
| Surface | acid surface or polishing, sand blasted surface |
| Shape | Square |
| Application | Metallurgy, electronics, medical, chemical, petroleum, pharmaceutical, aerospace, etc. |
Hardness, Brinell | 120 | 120 | annealed |
Hardness, Knoop | 132 | 132 | Estimated from Brinell. |
Hardness, Rockwell B | 70 | 70 | annealed |
Hardness, Vickers | 122 | 122 | Estimated from Brinell |
Tensile Strength, Ultimate | 240 MPa | 34800 psi | – |
Tensile Strength, Yield | 170 – 310 MPa | 24700 – 45000 psi | – |
Elongation at Break | 24 % | 24 % | – |
Reduction of Area | 35 % | 35 % | – |
Modulus of Elasticity | 105 GPa | 15200 ksi | In Tension |
Compressive Modulus | 110 GPa | 16000 ksi | – |
Poisson’s Ratio | 0.37 | 0.37 | – |
Charpy Impact | 310 J | 229 ft-lb | V-notch |
Shear Modulus | 45 GPa | 6530 ksi | – |
|
Physical Properties |
Metric |
English |
|
Density |
4.51 g/cc |
0.163 lb/in³ |
| Physical Properties | Metric | English |
|---|---|---|
| Density | 4.51 g/cc | 0.163 lb/in³ |
|
STANDARD |
WERKSTOFF NR. |
UNS |
|
Titanium |
3.7035 / 3.7165 / 3.7235 |
R50400 / R56400 / R52400 |
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@chuckmetals.com
Titanium Square Bars offer exceptional strength, lightweight properties, and corrosion resistance, making them ideal for high-performance applications in aerospace, medical, and industrial sectors.
Titanium Square Bars maintain excellent strength and stability even at elevated temperatures, making them suitable for use in extreme environments like aerospace engines and high-temperature industrial processes.
You’ll find Titanium Square Bars widely utilized across various high-performance industries thanks to their outstanding mechanical and corrosion-resistant properties. In aerospace, they’re essential for structural components, engine parts, and landing gear. Their ability to resist saltwater corrosion makes them a go-to choice in marine environments for shipbuilding and offshore projects. The medical field relies on titanium bars for surgical instruments and implants due to their biocompatibility. They’re also used in chemical processing equipment, automotive parts, and sports gear. Plus, their lightweight yet strong nature makes them ideal for architectural and industrial applications that require durability and performance.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
