Titanium Grade 4 Bars/Rods

Chuck Metals stands out as a trusted manufacturer and supplier of high-quality Titanium Grade 4 Bars and Rods in Singapore, specifically in Pulau Ujong. Renowned for their precision-engineered titanium products, Chuck Metals serves a variety of industries, including aerospace, chemical processing, marine, and medical sectors. Titanium Grade 4 is recognized as the strongest among all commercially pure titanium grades, providing an impressive mix of high strength, corrosion resistance, and biocompatibility. Chuck Metals guarantees that all bars and rods are produced to meet strict international standards, ensuring full traceability and quality assurance. Their dedication to reliability and performance makes them a go-to supplier for Titanium Grade 4 round bars and rods.

Titanium ASTM B348 Rods Exporter in Singapore, Ti Grade 4 Round Bars Stockist in Singapore, Titanium UNS R50700 Flat Bar Supplier in Singapore, Titanium UNS R50700 Cold Drawn Hex Bars Distributor in Clementi, Ti Grade 4 Rods Stockist Queenstown, Titanium UNS R50700 Hexagonal Bars Price in Queenstown, Titanium Alloy ASTM B348 Square Bar & Rods Singapore, Titanium DIN 3.7065 Bright Round Bars Supplier in Clementi, Ti Alloy DIN 3.7065 Hex Bar Supplier in Singapore, ASTM B348 Ti Alloy Cold Drawn Rods Exporter in Sengkang

Titanium Gr. 4 Round Bars

Titanium Alloy Gr.4 Rectangular Bars

Ti Grade 4 Square Rods

What is Titanium Grade 4 Bars/ Rods?

Titanium Grade 4 (UNS R50700) is a commercially pure titanium alloy with very few alloying elements. It generally contains at least 99.2% Titanium, along with trace amounts of Oxygen (up to 0.40%), Iron, Nitrogen, Carbon, and Hydrogen. This grade boasts the highest strength among commercially pure titanium grades, featuring a tensile strength ranging from 550 to 750 MPa and a yield strength of about 480 MPa, all while maintaining good ductility and corrosion resistance. It excels in both oxidizing and chloride-rich environments. Its outstanding biocompatibility, weldability, and mechanical performance make Grade 4 perfect for critical applications in tough conditions.

Titanium Alloy UNS R50700 Polished Bars Exporter in Singapore, DIN 3.7065 Titanium Bright Rods Exporter in Singapore, Grade 4 Ti Alloy Hollow Rods Manufacturer in Queenstown, Ti UNS R50700 Rectangular Bars Distributor in Singapore, Titanium Alloy Grade 4 Square Rods Dealer in Sengkang, Titanium Alloy UNS R50700 Square Bars Size Chart in Clementi, Ti DIN 3.7065 Hollow Bars Stockist in Singapore, Ti Grade 4 Hexagonal Rods Price List Sengkang, Ti Bar/Rods Weight Chart

Titanium Gr.4 Bars/ Rods Specifications

Standards :	ASTM B348, B863 / ASME SB348, SB863
Dimensions :	EN, DIN, JIS, ASTM, BS, ASME, AISI
Wire :	Thickness starting from 0.05mm
Round bar size :	Diameter: 3-~800mm
Hex Bar size :	2-100mm A/F
Flat bar size :	Thickness: 2 -100mm / Width: 10 to 500mm
Square bar size :	4 to 100mm
Rectangular Bars Size :	33 x 30mm to 295 x 1066mm
Hollow Bar :	32mm OD x 16mm ID to 250mm OD x 200mm ID
Tolerance :	H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements
Finish :	Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish

Titanium Gr.4 Bars/ Rods Equivalent Grades

STANDARD	WERKSTOFF NR.	UNS
Titanium Gr 4	3.7065	R50700

You Need Our Support, to Have Any Projects?

Test Certificate

Why Chuck Metals?

Packaging

Titanium Gr.4 Bars/ Rods Chemical Composition

Grade	C	N	O	H	Ti	Fe
Titanium Grade 4	0..08 max	0.05 max	0.40 max	0.015 max	Bal	0.50 max

Titanium Gr.4 Bars/ Rods Mechanical Properties

Tensile Strength	Reduction of area	Elongation	Hardness
552	25 %	15 %	100

Titanium Gr.4 Bars/ Rods Physical Properties

Density	Electrical conductivity (% IACS)	Thermal conductivity (BTU-in/hr-ft²-°F)	Specific heat (BTU/lb-°F)	Thermal expansion (1/°F)	Melting Point (°F)
0.163	2.87	119	0.127	0.00000478	3020

Titanium Grade 4 Bar and Rods Sizes

Type	SIZES (mm)	SIZES (Inches)	ISO Tolerance
Cold Drawn and Ground	10.00 – 75.00	5/6″ – 2.50″	h8-h9-h10-h11
Peeled and Polished	40.00 – 150.00	1.50″ – 6.00″	h11, h11-DIN 1013
Peeled and Ground	20.00 – 50.00	3/4″ – 2.00″	h9-h10-h11
Cold Drawn and Polish	3.00 – 75.00	1/8″ – 3.00″	h8-h9-h10-h11

Titanium Grade 4 Bars Standard lengths of 2000 mm up to 6000 mm. Cut to size on request (tolerance +2/-0 mm).

5.0	45.0
6.0	50.0
7.0	55.0
8.0	60.0
9.0	65.0
10.0	70.0
12.0	75.0
16.0	80.0
20.0	90.0
25.0	100.0
30.0	130.0
35.0	160.0
40.0	200.0

Modern Equipments

Expert Engineers

Well Maintained

Efficient Factories

Titanium Grade 4 Bar and Rods Types

Ti Grade 4 Rods Dealer in Sengkang, Titanium UNS R50700 Round Bars Manufacturer in Sengkang, Titanium Alloy DIN 3.7065 Cold Drawn Round Bar Dimensions Singapore, Titanium ASTM B348 Hex Bars Size Chart, Titanium Alloy Grade 4 Rods Price in Queenstown, Stockist of Ti ASTM B348 Rectangular Bars in Singapore, Ti Grade 4 Flat Rods Supplier in Singapore, Alloy UNS R50700 Round Bar Price List in Singapore, Ti Alloy Rectangular Bar and Rods Weight Chart

Titanium Grade 4 Bars and Rods Uses

Titanium DIN 3.7065 Bars and Rods are widely used in industries that require high strength, excellent corrosion resistance, and lightweight materials. These bars and rods are commonly employed in aerospace, marine, medical, and chemical processing industries. In aerospace, they are used for structural components and fasteners due to their strength and weight benefits. The medical industry utilizes Titanium Grade 4 for implants and surgical instruments, given its biocompatibility. Additionally, in marine and chemical applications, it is favored for its resistance to seawater corrosion and aggressive environments. Other uses include automotive and sports equipment where durability and performance are critical.

Our Products

Other Products

Other Material

If You Are Looking To Buy High Quality

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
