Chuck Metals stands out as a top manufacturer and supplier of Aluminium Bars and Rods in Singapore, Pulau Ujong. They offer a wide array of high-quality aluminium products designed for various industrial needs. With a commitment to precision and consistency, Chuck Metals supplies aluminium bars and rods in different grades, shapes, and sizes, catering to industries like aerospace, automotive, marine, construction, and electrical. These aluminium products are celebrated for their lightweight nature, resistance to corrosion, and impressive strength, all crafted to meet global standards for reliable performance in both structural and high-performance settings.
The Aluminium Bars and Rods are made from a selection of alloys, including 6061, 6082, 7075, 2024, 1050, and 5083. Each grade boasts unique mechanical properties, with tensile strengths ranging from 100 MPa to over 550 MPa, depending on the alloy and temper. They are known for their excellent corrosion resistance, good weldability, high thermal and electrical conductivity, and outstanding machinability. The uniform grain structure achieved during processing boosts their durability, making them perfect for both load-bearing and precision-machined components.
ASTM B211/ASME SB211 – Specification for Aluminum and Aluminum-Alloy Rolled or Cold Finished Bar, Rod
ASTM B221/ASME SB221 – Specification for Aluminum and Aluminum-Alloy Extruded Bars, Rods
ASTM B565/ASME SB565 – Test Method for Shear Testing of Aluminum and Aluminum-Alloy Rivets and Cold-Heading Rods
ASTM B316/ASME SB316 – Standard Specification for Aluminum and Aluminum-Alloy Rivet and Cold-Heading bars and Rods
AMS 4102/ISO Al99.0Cu – Standard Specification for Aluminum and Aluminum-Alloy Cold / Hot Rolled Bars, Rods
| Element | % Present |
| Al | 96 to 98.5 |
| Si | 0.7 to 1.3 |
| Mg | 0.4 to 0.8 |
| Mn | 0.4 to 0.8 |
| Fe | 0 to 0.5 |
| Zn | 0 to 0.2 |
| Ti | 0 to 0.2 |
| Cu | 0 to 0.1 |
| Others (Total) | 0.0 – 0.15 |
| Other (Each) | 0.0 – 0.05 |
| Temper | Tensile | Hardness | ||||
| Ultimate | Yield | Elongation | Brinell | |||
| KSI | MPA | KSI | MPA | % | ||
| T6, T651 | 45 | 310 | 21 | 145 | 25 | 65 |
Yes, aluminum bars are corrosion-resistant due to the formation of a natural oxide layer on the surface, which protects them from rust and deterioration, especially in various environmental conditions.
Yes, aluminum rods can be customized in size and length according to specific requirements. Manufacturers can cut, shape, and tailor the rods to meet precise specifications for various applications.
Aluminium bars perform poorly in high-temperature environments, as they lose strength and can soften at temperatures above 150-200°C. They are prone to oxidation and are unsuitable for extreme heat applications.
Aluminium Bars and Rods find their way into a multitude of industries thanks to their versatility and performance. In aerospace, they’re essential for aircraft frames, wing supports, and internal components. The automotive industry counts on them for engine parts, drive shafts, and suspension systems. In marine applications, their resistance to saltwater corrosion makes them ideal for structural components and fixtures. The electrical and electronics sectors use aluminium rods for conductors and connectors, while the construction industry incorporates them in window frames, railings, and structural reinforcements.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
