Chuck Metals is a top-notch manufacturer and supplier of high-quality Alloy 20 Forgings, proudly based in Singapore, Pulau Ujong. Known for their precision engineering and exceptional material integrity, Chuck Metals caters to a variety of industrial sectors, including chemical processing, marine, and oil & gas. They offer tailored forging solutions that meet international standards, serving both local and global clients. Their dedication to quality, timely delivery, and customer satisfaction has earned them a solid reputation in the specialty metals market. What sets Chuck Metals apart is their blend of innovation, technical know-how, and responsive service, all aimed at adapting to the ever-changing demands of the industry.
Alloy 20 Forgings are primarily made up of nickel (32–38%), chromium (19–21%), and iron, with added copper (3–4%), molybdenum (2–3%), and columbium (niobium). This unique composition gives them outstanding corrosion resistance, especially in sulfuric acid environments. The mechanical properties are impressive, featuring a tensile strength of about 80 ksi (550 MPa), yield strength of 35 ksi (240 MPa), and an elongation range of 30–40%. Alloy 20 also boasts good creep resistance and high toughness, making it ideal for challenging chemical and high-temperature settings where reliability is crucial.
| Specifications | ASTM B462, ASME SB462 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | S | Cu | Ni | Cr | Fe | Mo | P |
| Alloy 20 | 0.07 max | 2.00 max | 1.00 max | 0.035 max | 3.00 – 4.00 | 32.00 – 38.00 | 19.00 – 21.00 | 29.85 min* | 2.00 – 3.00 | 0.045 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Alloy 20 | 8.1 g/cm3 | 1443 °C (2430 °F) | Psi -80,000, MPa -551 | Psi – 35,000, MPa – 241 | 30 % |
| STANDARD | WERKSTOFF NR. | UNS | EN | AFNOR |
| Alloy 20 | 2.4660 | N08020 | NiCr20CuMo | Z2NCUD31-20AZ |
Yes, Alloy 20 forgings are highly resistant to corrosion, particularly against sulfuric acid, making them ideal for chemical processing environments. Their excellent resistance ensures durability and longevity in harsh conditions.
The maximum operating temperature for Alloy 20 forgings is typically around 1000°F (537°C). However, it is important to consider application conditions and potential stress factors to ensure optimal performance.
Yes, Alloy 20 forgings can be customized for specific applications. They are tailored to meet unique requirements, offering excellent corrosion resistance, durability, and strength for various industrial uses.
Alloy 20 Forgings find extensive use in industries that demand strong corrosion resistance and durability. You’ll commonly see them in heat exchangers, chemical process piping, reactor vessels, and storage tanks within the petrochemical and pharmaceutical fields. They are particularly effective for handling sulfuric acid and other harsh chemicals. Additionally, Alloy 20 is utilized in marine hardware, food processing equipment, and power generation plants. Thanks to its resistance to pitting, crevice corrosion, and stress corrosion cracking, it’s a go-to material for high-performance and safety-critical components. Its versatility and dependability ensure a long service life, even in tough operating conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
