Chuck Metals, based in Singapore on Pulau Ujong, stands out as a top-notch manufacturer and supplier of high-quality steel products, including their renowned Carbon Steel E-200 Bars. These bars are celebrated for their excellent machinability, moderate strength, and dependable performance in a variety of general-purpose applications. Crafted with precision to meet industry standards, Chuck Metals takes pride in ensuring that every batch is produced using cutting-edge techniques and rigorous quality control processes, guaranteeing consistent chemical composition and dimensional accuracy. Perfect for situations where easy machining and cost-effectiveness are key, Carbon Steel E-200 Bars find their place in the manufacturing, automotive, and construction industries, both locally and around the globe.
Carbon Steel E-200 Bars are classified as low-carbon steels, typically containing about 0.15–0.25% carbon, along with trace amounts of manganese and silicon. This specific blend offers great machinability and weldability while providing sufficient tensile strength in the range of 400–550 MPa. While these bars are generally not heat-treated, they can be cold-drawn to enhance their mechanical properties and surface finish. E-200 is ideal for non-critical structural and mechanical components where extreme strength isn’t a necessity. Produced in accordance with industry standards like EN and BS, Chuck Metals’ E-200 Bars strike a perfect balance between affordability, performance, and ease of fabrication.
| Specifications | : | ASTM A105, ASME SA105 |
| Dimensions | : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Carbon Steel EN Series Round Bars | : | 3.0 – 50.8 mm, Over 50.8 – 300mm |
| Carbon Steel EN Series Rectangular Bars | : | 6.35 x 12.7mm,6.35 x 25.4mm,12.7 x 25.4mm |
| Carbon Steel EN Series Hex Bars | : | AF5.8mm–17mm |
| Carbon Steel EN Series Square Bars | : | AF2mm – 14mm, AF6.35mm,9.5mm,12.7mm, 15.98mm,19.0mm, 25.4mm |
| Carbon Steel EN Series Flat Bars | : | 1/2” to 10” in thickness range of 2mm to 150mm, |
| Finish | : | Bright, Polish & Black |
| Length | : | 1 to 6 Meters, Custom Cut Lengths |
| Form | : | Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc. |
| Grade | ||||||
| C% | Si% | Mn% | Cr% | Mo% | W% | |
| EN-1A | 0.007 TO 0.15 | 0.10 | 0.80 TO 1.00 | S | P | – |
| 0.20 TO 0.30 | 0.70 MAX | |||||
| EN-8 | 0.35 TO 0.45 | 0.05 TO 0.30 | 0.60 TO 1.00 | S | P | – |
| 0.06 MAX | 0.06 MAX | |||||
| EN-9 | 0.50 TO 0.60 | 0.05 TO 0.30 | 0.5 TO 0.80 | – | – | – |
| EN-19(V 320) | 0.35 TO 0.45 | 0.10 TO 0.30 | 0.5 TO 0.80 | 0.90 TO 1.40 | 0.20 TO 0.40 | |
| EN-24(V 130) | 0.35 TO 0.45 | 0.10 TO 0.35 | 0.45 TO 0.70 | 0.90 TO 1.40 | 0.20 TO 0.35 | NI |
| 1.3 TO 1.8 | ||||||
| EN-31 R-100 | 0.90 TO 1.20 | 0.10 TO 0.35 | 0.30 TO 0.75 | 1.00 TO 1.60 | – | – |
| EN-36C E-200 | 0.12 TO 0.18 | 0.10 TO 0.35 | 0.30 TO 0.60 | 0.60 TO 1.10 | – | NI |
| 3.0 TO 3.75 | ||||||
| EN-42 | 0.70 TO 0.85 | 0.10 TO 0.40 | 0.55 TO 0.75 | – | – | – |
| EN-44 | 0.90 TO 1.20 | 0.30 | 0.45 TO 0.70 | – | – | – |
| EN-45 F-110 | 50 TO 0.60 | 1.5 TO 2.0 | 0.70 TO 1.00 | – | – | – |
| EN-351 | 0.10 TO 0.20 | 0.35 | 0.60 TO 1.00 | 0.40 to 0.80 | 0.08 to 0.10 | NI |
| 0.60 TO 1.00 | ||||||
| EN-353 | 0.10 TO 0.20 | 0.35 | 0.50 TO 1.00 | 0.75 TO 1.25 | 0.08 to o.15 | NI |
| 1.00 TO 1.50 |
| Grade | HEAT TREATMENT | CORRESPONDING SPECIFICATION | |||||
| Hardening Temperature | Quenching Medium | Tempering Temperature | Brinell Rock well hardness | JAPAN JIS | AISI | POLDI THREAD | |
| EN-1A | – | – | – | – | – | – | – |
| EN-8 | 750-900 | OIL | 150-200 | ||||
| EN-9 | 850-900 | OIL | 200-250 | 55-60 | |||
| EN-19 (V 320) | 900-950 | OIL | 200-225 | 45-55 | SCM 4 | 4140 | |
| EN-24 (V 130) | 830-860 | OIL | 540-680 | 45-55 | SNCM 8 | 4340 | |
| EN-31 R-100 | 820-860 | OIL | 180-225 | 59-65 | |||
| EN-36C E-200 | 780-860 | OIL | 170-210 | 61-63 | SNC 22 | 3415 | |
| EN-42 | 600-700 | DIRECT HARDENING | 40-45 | ||||
| EN-44 | 650-750 | OIL | 150 | 45-50 | |||
| EN-45 | 830-860 | OIL | 470-520 | 50-55 | 9255 | ||
| EN-351 | 850-860 | OIL | 175-200 | 62-64 | |||
| EN-353 | 840-870 | OIL | 150-200 | 62-64 | |||
Common finishes for Carbon Steel E-200 Bar include hot rolled, cold rolled, polished, pickled, galvanized, and painted, each providing varying levels of surface smoothness, corrosion resistance, and appearance.
Yes, Carbon Steel E-200 Bar is available in various lengths. Suppliers typically offer customizable options, ranging from standard sizes to specific lengths according to customer requirements.
Carbon Steel E-200 Bar is commonly used in structural applications, manufacturing of automotive parts, machinery, tools, and general fabrication due to its strength, durability, and resistance to wear and corrosion.
In various industries that require components with low to moderate strength and excellent machinability, Carbon Steel E-200 Bars are a popular choice. In construction, they are utilized for general fabrication, support structures, and brackets. In manufacturing, they play a vital role in producing fasteners, bushings, pins, and light-duty shafts. Automotive and agricultural equipment manufacturers rely on E-200 Bars for parts that don’t face high stress but still need to be easy to machine and form. These bars are also well-suited for welding and are frequently used in maintenance and repair tasks. Chuck Metals’ E-200 Bars deliver reliable, cost-effective solutions for a wide range of applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
