Incoloy Bright Bars

Chuck Metals is a well-respected manufacturer and supplier based in Singapore, Pulau Ujong, known for its top-notch Incoloy Bright Bars that are built to excel in tough environments. These bars are crafted from high-quality nickel–iron–chromium alloys, which give them impressive mechanical strength along with remarkable resistance to oxidation, carburization, and corrosion at high temperatures. The bright finish not only ensures precise dimensions and smooth surfaces but also adds a touch of aesthetic appeal, making them perfect for both practical and decorative uses. Chuck Metals offers Incoloy Bright Bars in a variety of grades and sizes, all adhering to international quality standards for industries like petrochemical, marine, chemical processing, and power generation.

Incoloy Bright Bar Supplier in Singapore, Incoloy Cold Drawn Bright Bars Distributor in Clementi, Alloy Bright Rods Stockist Queenstown, Incoloy Bright Rods Exporter in Singapore, Incoloy Bright Bars Price in Queenstown, Incoloy Bright Bar & Rods Singapore, Incoloy Bright Bars Weight Calculator, Incoloy Alloy Bright Bar Supplier in Singapore, Alloy Cold Drawn Bright Rods Exporter in Sengkang, Alloy Bright Bars Stockist in Singapore

Incoloy Alloy Bright Bars

Incoloy Alloy Polished Bright Bars

Incoloy Cold-Finished Bright Rods

What is Incoloy Bright Bars?

Incoloy Bright Bars primarily consist of nickel (30–46%), chromium (19–24%), and iron, with small amounts of titanium, aluminum, molybdenum, and other elements tailored to specific grades. These bars boast tensile strength between 500–750 MPa, yield strength from 200–350 MPa, and excellent elongation properties. They maintain their stability and mechanical integrity even under high thermal stress and corrosive conditions, ensuring they perform reliably over the long haul.

Incoloy Bright Rods Dealer in Sengkang, Incoloy Bright Bars Manufacturer in Sengkang, Incoloy Cold Drawn Bright Bar Supplier in Singapore, Incoloy Bright Bars Size Chart, Incoloy Bright Rods Price in Queenstown, Stockist of Incoloy Bright Bars in Singapore, Incoloy Bright Bars Supplier in Singapore, Alloy Bright Bar Price List in Singapore

Incoloy Bright Bars Specifications

Dimensions	BS, DIN, EN, AISI, JIS, ASME, ASTM
Size of Round Bars	Thickness: 2 milimeter-100 milimeter
Surface	Bright, Hot Rolled Pickled, Hairline, Cold Drawn, Sand Blasting Finished, Polished
Processing	cutting to 650 milimeter
Tolerance	H9, K9, H8, H12, K12, H11, H13, K10, K11, H10, or as per need
Finish	centreless ground, Cold (bright) drawn, smooth turned, hot rolled, slit rolled edge, peeled, Rough Turned, hot rolled annealed, Polish, Bright, Centreless Ground, Grinding & Black
Method	Cold Drawn, Hot Rolled, Cold Rolled Rod, Forged Round Bars
Condition	annealed, Hardened & tempered

You Need Our Support, to Have Any Projects?

Test Certificate

Why Chuck Metals?

Packaging

Incoloy Bright Bars Physical Properties

Density	g/cm3	7.94
Density	lb/in.3	0.287
Melting Range	°F	2475 – 2525
Melting Range	°C	1357 – 1385

Incoloy Bright Bars Mechanical Properties

Condition & Size	Tensile Strength	Yield Strength (0.2% Offset)	Elongation	Reduction of Area	Hardness
Condition & Size	MPa, min	MPa, min	%, min	%, min	Rockwell, max
Hot worked, as-hot-worked	550	240	25	…	…
Cold-worked and hot-worked, annealed	515	205	30	…	…

Incoloy Bars & Rod Size Chart

US Bar		Metric		Japanese		Canadian/ASTM
Diam. (Inch)	Bar Size	Diam. (mm)	Bar Size	Diameter (mm)	Bar Size	Diameter (mm2)	Bar Size
0.250	#2	5	5	6	6	100	10M
0.375	#3	5.5	5.5	10	10	200	15M
0.500	#4	6	6	13	13	300	20M
0.625	#5	7	7	16	16	500	25M
0.750	#6	8	8	19	19	700	30M
0.875	#7	9	9	22	22	1000	35M
1.000	#8	10	10	25	25	1500	45M
1.125	#9	11	11	29	29	2500	55M
1.250	#10	12	12	32	32
1.375	#11	14	14	35	35
1.500	#12	16	16	38	38
1.625	#13	18	18	41	41
1.750	#14	20	20	44	44
1.875	#15	22	22	48	48
2.000	#16	25	25	51	51
2.250	#18	28	28	57	57
		32	32
		36	36
		40	40
		44	44
		50	50

Incoloy Round Bars Weight Chart

Size	kilogram / Meter	kilogram / Foot	Size	kilogram / Meter	kilogram / Foot	Size	kilogram / Meter	kilogram / Foot
1/8″	0.062	0.019	22mm	2.979	0.908	3-1/4″	41.996	12.800
3mm	0.055	0.017	20mm	2.470	0.753	3″	35.762	10.900
4mm	0.098	0.030	24mm	3.543	1.080	3-3/4″	55.780	17.001
5/32″	0.095	0.029	7/8″	3.038	0.926	3-1/2″	48.772	14.850
5mm	0.154	0.047	1″	3.970	1.210	4-1/4″	72.249	21.908
3/16″	0.141	0.043	25mm	3.871	1.180	4″	63.340	19.306
6mm	0.223	0.068	27mm	4.490	1.368	4-3/4″	90.249	27.366
7/32″	0.190	0.058	26mm	4.170	1.271	4-1/2″	80.340	24.4487
7mm	0.298	0.091	30mm	5.548	1.691	5-1/2″	121.000	36.690
1/4″	0.249	0.076	1-1/8″	5.033	1.534	5″	99.940	30.461
8mm	0.398	0.120	32mm	6.314	1.894	6-1/2″	167.630	51.093
5/16″	0.387	0.118	1-1/4″	6.349	1.924	6″	143.900	43.860
3/8″	0.557	0.170	35mm	7.553	2.390	7-1/2″	225.000	68.226
9mm	0.498	0.152	1-3/8″	7.550	2.303	7″	196.000	59.432
11mm	0.748	0.228	38mm	8.903	2.792	10″	397.140	121.048
10mm	0.620	0.189	36mm	7.999	2.438	8″	254.55	77.586
12mm	0.889	0.271	40mm	9.872	3.009
7/16″	0.761	0.232	1-1/2″	8.951	2.715
13mm	1.043	0.318	1-3/4″	12.179	3.712
1/2″	0.994	0.303	1-5/8″	10.449	3.200
9/16″	1.256	0.383	1-7/8″	13.977	4.260
14mm	1.207	0.368	45mm	12.555	3.807
5/8″	1.551	0.473	50mm	15.414	4.698
15mm	1.391	0.424	48mm	14.205	4.330
17mm	1.791	0.543	2-1/8″	17.963	5.475
16mm	1.578	0.481	2″	15.906	4.848
18mm	2.001	0.610	60mm	22.205	6.768
11/16″	1.880	0.573	2-1/4″	20.128	6.135
3/4″	2.237	0.682	2-3/8″	22.435	6.838
			2-1/2″	24.856	7.576
			2-5/8″	27.409	8.354
			2-3/4″	30.083	9.169	–	–	–

Modern Equipments

Expert Engineers

Well Maintained

Efficient Factories

Incoloy Bright Bars Types

Incoloy Bright Bars Distributor in Singapore, Incoloy Alloy Bright Rods Dealer in Sengkang, Incoloy Bright Bars Supplier in Clementi, Incoloy Bright Bars Stockist in Singapore, Incoloy Polished Bright Bars Size Chart in Singapore, Incoloy Bright Rods Exporter in Singapore, Alloy Bright Bar Manufacturer in Queenstown

Frequently Asked Questions (FAQ)

What are the Key Benefits of Using Incoloy Bright Bars?

Incoloy bright bars offer excellent corrosion resistance, high-temperature strength, durability, oxidation resistance, and versatility in extreme environments.

Can Incoloy Bright Bars be Customized for Specific Applications?

Yes, Incoloy bright bars can be customized to meet specific dimensional, strength, and material requirements for various applications. This customization ensures optimal performance in industries such as aerospace, chemical processing, and power generation.

Do Incoloy Bright Bars Require Corrosion Protection Coatings?

Incoloy bright bars generally have excellent corrosion resistance due to their alloy composition, reducing the need for additional protective coatings. However, in highly aggressive environments, extra coatings or surface treatments may be applied for enhanced protection.

Incoloy Bright Bars Uses

These bars find extensive applications in furnace equipment, chemical processing units, heat exchangers, marine hardware, and pollution control systems. Their bright, polished surface finish makes them ideal for precision engineering tasks, while their resistance to corrosion and oxidation guarantees dependability in high-temperature and high-pressure settings. Incoloy Bright Bars are also popular in the food processing, pulp and paper, and aerospace industries due to their durability and exceptional finish.
