Chuck Metals is a trusted name in Singapore, Pulau Ujong, known for manufacturing and supplying top-notch alloy products. They specialize in high-quality Inconel 792 Bars and Rods, perfect for those critical high-temperature applications. With a reputation for precision manufacturing and rigorous quality checks, Chuck Metals ensures that their products meet the demanding standards of industries like aerospace, power generation, and metallurgy. Inconel 792 is specifically designed to excel in environments that require outstanding strength and resistance to oxidation. Thanks to their reliable service, quick delivery, and solid technical support, Chuck Metals has become the go-to choice for clients seeking high-performance materials that can handle extreme thermal and mechanical conditions.
Inconel 792 Bars and Rods are nickel-based superalloys, made up of about 58–62% nickel, 12–14% chromium, 3–5% aluminum, and 8–10% cobalt, along with small amounts of titanium, molybdenum, and zirconium. These bars are precipitation-hardened to boost their strength and are renowned for their exceptional stability at high temperatures. The alloy boasts a tensile strength of around 930 MPa and a yield strength close to 750 MPa. It also shows remarkable resistance to oxidation and thermal fatigue at temperatures over 1000°C. The well-balanced composition of Inconel 792 makes it perfect for structural components that face prolonged stress and heat, especially in challenging engine and turbine settings.
| Specifications | ASTM B116 / ASTM SB116 |
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Size | 5 mm to 500 mm |
| Diameter | 0.1 mm to 100 mm |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Length | 100 mm To 3000 mm Long & Above |
| Form | Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc. |
| Element | Composition (%) |
| Nickel (Ni) | 60.0 – 65.0 |
| Chromium (Cr) | 12.0 – 14.0 |
| Cobalt (Co) | 9.0 – 10.0 |
| Aluminum (Al) | 3.0 – 4.5 |
| Titanium (Ti) | 3.5 – 4.5 |
| Molybdenum (Mo) | 1.5 – 2.5 |
| Tantalum (Ta) | 0.50 – 1.50 |
| Zirconium (Zr) | 0.02 – 0.15 |
| Boron (B) | 0.010 – 0.020 |
| Carbon (C) | 0.12 – 0.20 |
| Silicon (Si) | ≤ 0.50 |
| Manganese (Mn) | ≤ 0.50 |
| Iron (Fe) | ≤ 3.0 |
| Property | Value |
| Tensile Strength | 1000 – 1400 MPa |
| Yield Strength (0.2%) | 800 – 1100 MPa |
| Elongation | 5 – 15% |
| Hardness | 350 – 450 HB |
| Impact Strength | Good at elevated temperatures |
| Property | Value |
| Density | 8.25 g/cm³ |
| Melting Range | 1260 – 1340°C |
| Thermal Conductivity | 11.2 W/m·K at 20°C |
| Specific Heat Capacity | 0.410 J/g·K at 20°C |
| Electrical Resistivity | 1.22 μΩ·m at 20°C |
| Coefficient of Thermal Expansion | 13.3 x 10⁻⁶ /°C (20-1000°C) |
Inconel 792 Bars and Rods find their primary use in aerospace and industrial gas turbines, thanks to their ability to endure extreme heat and mechanical stress. You’ll often see them in turbine blades, vanes, combustor parts, and other high-temperature components that are subjected to oxidation and thermal cycling. The alloy’s impressive fatigue resistance and creep strength make it ideal for rotating parts in jet engines and land-based turbines. Additionally, Inconel 792 is utilized in industrial furnaces, chemical reactors, and power generation systems where maintaining long-term structural integrity is crucial. Its durability and thermal stability make it a reliable choice for these demanding applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
