Chuck Metals is a well-known manufacturer and supplier of Nitronic 40 Bars and Rods based in Singapore, Pulau Ujong. They specialize in high-strength, corrosion-resistant austenitic stainless steel products designed for critical applications. Nitronic 40 stands out for its impressive mechanical properties, excellent oxidation resistance, and remarkable performance in both cryogenic and high-temperature settings. Chuck Metals provides precision-engineered Nitronic 40 bars and rods that meet international standards, making them perfect for industries like aerospace, chemical processing, and marine. With a strong focus on quality, reliability, and timely delivery, Chuck Metals has earned a reputation as a trusted partner for advanced stainless steel solutions.
The composition of Nitronic 40 Bars and Rods primarily includes iron, with significant amounts of chromium (19–21%), nickel (8.5–10.5%), and manganese (4–6%), plus nitrogen to enhance strength. This alloy offers better corrosion resistance than 304 and 316 stainless steels while maintaining excellent strength and toughness at both low and high temperatures. Typically, Nitronic 40 has a tensile strength of about 750 MPa and is non-magnetic when annealed. It also boasts good weldability and formability, making it suitable for structural and pressure-containing applications.
| Grade | Nitronic alloy 40 Round Bar bars |
|---|---|
| Specification | DIN, JIS, ASTM, BS, ASME, AISI |
| Nitronic 40 Square bar size | 4 to 100mm |
| Nitronic Alloy 40 Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| 40 Nitronic Alloy Hex Bar size | 2-100mm A/F |
| Nitronic 40 Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Nitronic Alloy 40 Rectangles Size | 33 x 30mm to 295 x 1066mm |
| 40 Nitronic Alloy Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Nitronic 40 Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Nitronic Alloy 40 Section | 3.0 to 12.0mm thickness |
| 40 Nitronic Alloy Round bar size | Diameter: 3-~800mm |
| Nitronic 40 Billet Size | 1/2″ to 495mm Diameter |
| Nitronic Alloy 40 Round Bar Standard Dimensions | Diameter / Height: |
| Nitronic 40 Surface | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| Nitronic Alloy 40 Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| 40 Nitronic Alloy Technique | Nitronic 40 Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| Nitronic 40 Condition | Hardened & tempered, annealed |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Form | Nitronic 40 Round, Rod, T-Bar, Nickel Alloy Channel Bar, Precision Ground Bar, Nickel Alloy Flat Bar, Nickel Alloy Square Bar, Nickel Alloy Blocks, Nickel Alloy Round Rod, Nickel Alloy Rings, Nickel Alloy Hollow, Nickel Alloy Triangle, Rectangle, Hex (A/F), Nickel Alloy Threaded, Half Round Bar, Profiles, Nickel Alloy Billet, Nickel Alloy Ingot, I/H Bar, Forging etc. |
| Processing | Bar cutting to 650mm |
| Our Nitronic 40 Round bar conforms to NACE MR0175/ISO 15156 | |
| Grade | C | Mn | S | Si | N | Ni | Cr |
| Nitronic Alloy 40 | 0.08 | 10.0 – 8.0 | 0.030 | 1.00 | 0.40 – 0.15 | 7.50 – 5.50 | 21.50 – 19.00 |
Ultimate Tensile, min. | Yield Strengtd (0.2% OS) min. | Elong. in 2 in., or 50mm, min., % | R/A | Hardness, max. | |
Min | 95 KSi | 48 KSi | 35 |
| |
Max | 241 Brinell | ||||
Min | 655 MPa | 330 MPa | |||
Max | 100 Rockwell B |
| STANDARD | UNS | DIN |
|---|---|---|
| Nitronic 40 Round Bars | S21900 | – |
Nitronic 40 bars are available in both rough and smooth finishes, depending on the manufacturing process and customer requirements. Smooth finishes are typical for applications needing better aesthetics or precision.
Nitronic 40 rods are available in sizes ranging from 3mm to 300mm diameter. Finishes include bright, polished, black, and rough-turned, catering to industrial and decorative applications.
Yes, Nitronic 40 bar can be welded using standard methods like TIG, MIG, and shielded metal arc welding. Preheating is not required, and post-weld annealing ensures optimal properties.
Nitronic 40 Bars and Rods find extensive use in aerospace components, cryogenic systems, heat exchangers, chemical processing equipment, and high-temperature structural parts. Their strength, toughness, and corrosion resistance make them ideal for jet engine components, missile parts, and marine applications. Furthermore, Nitronic 40 is utilized in pressure vessels and piping systems where mechanical reliability and resistance to stress corrosion cracking are crucial. Its outstanding performance across a variety of temperatures and environments makes Nitronic 40 a top choice in industries that demand both durability and versatility.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
