Chuck Metals, a leading manufacturer and supplier located in Singapore, Pulau Ujong, is dedicated to providing top-notch Super Duplex Steel S32750 Bars and Rods for industries that demand outstanding mechanical strength and resistance to corrosion. Also referred to as UNS S32750 or Alloy 2507, this super duplex stainless steel combines austenitic and ferritic structures, making it perfect for harsh environments. Chuck Metals offers these bars and rods in a variety of diameters and lengths, all precision-engineered to meet ASTM A479, A276, or A182 standards, ensuring top performance in marine, offshore, chemical processing, and structural applications.
Super Duplex S32750 consists of about 25% Chromium, 7% Nickel, and 4% Molybdenum, along with Nitrogen, Manganese, and trace amounts of Copper and Tungsten. This unique blend provides exceptional corrosion resistance and strength. The alloy boasts a minimum yield strength of 550 MPa, a tensile strength of at least 795 MPa, and an elongation of roughly 15–25%. Its high PREN (>40) makes it particularly resistant to pitting and crevice corrosion in chloride-rich environments, while its dual-phase microstructure ensures excellent resistance to stress corrosion cracking and impact toughness.
| Standard | ASTM A276, ASME SA276 |
| Round Bar Size | 3mm~ 800mm |
| Square Bar Size | 4mm* 4mm ~100mm* 100mm |
| Flat Bar Size | 2mm ~ 100mm |
| Hex Bar Size | 2mm ~ 100mm |
| Angle Size | 3mm* 20mm* 20mm~ 12mm* 100mm* 100mm |
| Thickness | 50 mm to 6000 mm Long |
| Length | 1 To 6 Meters, Custom Cut Length |
| Form | Round, Square, Hex(A/F), Rectangle, Billet, Ingot, Forging Etc |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S32750 | 0.030 max | 1.20 max | 0.80 max | 0.035 max | 0.020 max | 24.00 – 26.00 | 3.00 – 5.00 | 6.00 – 8.00 | 0.24 – 0.32 | 58.095 min |
| Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
| S32750 | 7.8 | 0.281 | 1350 | 2460 |
| STANDARD | WERKSTOFF NR. | UNS |
| Super Super Duplex S32750 | 1.4410 | S32750 |
Super Duplex Steel S32750 Bar & Rod is widely used in applications requiring exceptional strength and corrosion resistance. In the oil and gas industry, they are ideal for subsea pipelines, offshore platforms and heat exchangers. The chemical industry uses them in reactors and pressure vessels because of their resistance to pitting, stress and corrosion cracking In marine environments for shipbuilding, desalination plants and seawater systems. Pulp and paper companies use it in digesters and washing machines. In addition, they are used in power plants, aerospace and construction applications, providing high efficiency, durability and reliability in harsh environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
