Chuck Metals is a reliable manufacturer and supplier of high-purity copper products based in Singapore, Pulau Ujong. They offer top-notch Copper C10500 Bars and Rods, perfect for critical electrical, electronic, and industrial applications. C10500, also known as OFE Copper (Oxygen-Free Electronic), is celebrated for its outstanding conductivity and purity, making it a go-to choice for industries that need minimal electrical resistance and excellent formability. Chuck Metals provides copper rods and bars that meet precise tolerances, boast an excellent surface finish, and comply fully with international standards. With quick delivery and expert technical support, Chuck Metals ensures consistent performance for demanding copper applications.
The Copper C10500 Bars and Rods contain 99.99% pure copper with no residual oxygen, which gives them the highest electrical conductivity among commercially available copper grades—typically reaching ≥101% IACS. They also feature excellent thermal conductivity, low volatility, and remarkable ductility. In terms of mechanical properties, they have a tensile strength of about 220–300 MPa (when annealed), making them easy to machine, fabricate, and weld in sensitive applications. The lack of oxygen eliminates the risk of hydrogen embrittlement during high-temperature processing, which is vital for vacuum systems, electronics, and instrumentation that require absolute material integrity.
| Specifications | ASTM B187, ASTM B301 / ASME SB187, SB301 |
| Range | 3.17 MM TO 350 MM DIA |
| Form | Round, Square, Hex (A/F), Rectangle, Wire (Coil Form), Wire-mesh, Billet, Ingot, Forging Etc. |
| Copper Grades | C10500 |
| Elements | |||
|---|---|---|---|
| Cu(1,2,3) | Ag(4) | O | |
| (1) This is a high conductivity copper which has, in the annealed condition a minimum conductivity of 100% IACS except for Alloy C10100 which has a minimum conductivity of 101% IACS. (2) Cu value includes Ag. (3) Cu is determined by the difference between the impurity total and 100%. (4) Ag 0.034% min is the equivelant of, Ag 10 Troy Oz min. | |||
| Min (%) | 99.95 | 0.034 | |
| Max (%) | 0.001 | ||
| Form | Temper | Temper Code | Tensile Strength (ksi) | YS-0.5% Ext (ksi) | Elongation (%) | Rockwell B scale | Rockwell F scale | Rockwell 30T scale | Shear Strength (ksi) | Section Size (in) | Cold Work (%) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| * Measured at room temperature, 68°F (20°C). | |||||||||||
| Rod | As Hot Rolled | M20 | 32 Typ | 10 Typ | 55 Typ | 40 Typ | 22 Typ | 1 | |||
| Hard | H04 | 55 Typ | 50 Typ | 10 Typ | 60 Typ | 94 Typ | 29 Typ | 0.25 | 40 | ||
| Hard | H04 | 45 Typ | 40 Typ | 20 Typ | 45 Typ | 85 Typ | 26 Typ | 2 | 16 | ||
| Hard | H04 | 48 Typ | 44 Typ | 16 Typ | 47 Typ | 87 Typ | 27 Typ | 1 | 35 | ||
| Nominal Grain Size 0.050 mm | OS050 | 32 Typ | 10 Typ | 55 Typ | 40 Typ | 22 Typ | 1 | ||||
These Copper C10500 Bars and Rods are widely used in electrical conductors, vacuum tubes, semiconductor fabrication, superconducting systems, and RF components, thanks to their unmatched conductivity and purity. In the aerospace and defense sectors, they find applications in propulsion systems and high-frequency connectors. Laboratories and research facilities depend on C10500 copper for cryogenic applications and precision instrumentation. Its non-magnetic, corrosion-resistant properties and superior workability make it perfect for both structural and electrical uses where low impurity levels and thermal/electrical stability are crucial.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
