Chuck Metals is a well-respected manufacturer and supplier of Stainless Steel 316L Flat Bars in Singapore, serving a diverse array of industries throughout Pulau Ujong. Stainless Steel 316L is a low-carbon variant of 316, celebrated for its exceptional corrosion resistance, particularly in environments rich in chlorides and marine settings, along with its impressive weldability and formability. These flat bars are produced in line with international standards like ASTM A276, guaranteeing precise dimensions and reliable performance.
The composition of Stainless Steel 316L includes 16–18% chromium, 10–14% nickel, and 2–3% molybdenum, with a carbon content capped at 0.03%. This blend significantly boosts its resistance to pitting, crevice corrosion, and intergranular attack, especially post-welding. It boasts a tensile strength of about 485 MPa and a yield strength of around 170 MPa, making it ideal for structural and pressure applications.
Standard : ASTM A276, ASME SA276
Dimensions : EN, DIN, JIS, ASTM, BS, ASME, AISI, ASTM, ASME
Flat Bar Size : 2mm ~ 100mm
Thickness : 1/8″ – 3″
Width : 3/8” – 8”
finish : Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
|---|---|---|---|---|---|---|---|---|---|
| SS 316L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 1.0 max | 16.00 – 18.00 | 2.00 – 3.00 | 10.00 – 14.00 | 68.89 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.0 g/cm3 | 1399 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316L | 1.4404 / 1.4435 | S31603 | SUS 316L | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 | Z3CND17‐11‐02 / Z3CND18‐14‐03 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
Stainless Steel 316L flat bars primarily consist of 16-18% chromium, 10-14% nickel, and 2-3% molybdenum, with a maximum carbon content of 0.03%. This composition enhances corrosion resistance, especially in chloride-rich environments, making it ideal for demanding applications.
Stainless Steel 316L flat bars are commonly used in industries such as chemical processing, marine, food processing, pharmaceuticals, and petrochemicals. Their high corrosion resistance makes them ideal for applications exposed to aggressive chemicals, saltwater, and high-temperature environments.
The low carbon content in 316L stainless steel reduces carbide precipitation during welding, improving its resistance to intergranular corrosion. This enhances its overall corrosion resistance, particularly in chloride environments, and makes it suitable for applications requiring high strength and durability.
You’ll find 316L flat bars commonly used in chemical processing, food and beverage equipment, pharmaceutical manufacturing, marine structures, and architectural projects. Typical applications include support brackets, frames, structural reinforcements, and machined components. These bars deliver remarkable strength, corrosion resistance, and durability in harsh environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
