Chuck Metals is a reputable manufacturer and supplier based in Singapore, specifically on Pulau Ujong. They specialize in high-quality Incoloy 800HT Forgings, which are engineered for outstanding high-temperature strength and resistance to oxidation. These forgings are crafted from a nickel–iron–chromium alloy, with carefully measured amounts of aluminum and titanium added to enhance their creep and rupture properties. This makes them perfect for tough industrial settings. Chuck Metals is committed to precision engineering, rigorous quality control, and adherence to global standards, offering Incoloy 800HT Forgings in a variety of sizes and specifications. You’ll find these products commonly used in petrochemical plants, power generation facilities, heat-treating equipment, and furnace components.
Incoloy 800HT Forgings consist of nickel (30–35%), chromium (19–23%), and iron as the primary components, with a carbon content ranging from 0.06–0.10% and a combined aluminum and titanium content of 0.85–1.20%. They boast a tensile strength of around 520 MPa and a yield strength of about 205 MPa, while also maintaining excellent ductility and structural stability at temperatures up to 1100°C.
Specifications ASTM B564 / ASME SB564, AMS 5766
Flat bar blocks up to 27″ width and 15,000 lbs.
Cylinders and sleeves up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts up to 144″ maximum length and 20,000 lbs.
| Grade | Ni | Fe | Cr | Cu | Ti | Al | C | Mn | S | Si |
| Alloy 800HT | 30.0-35.0 | 39.5 min | 19.0-23.0 | .75 max | .25-.60 | .85-1.20 | .06-.10 max | 1.5 max | .015 max | 1.0 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.94 g/cm3 | 1350-1400 ℃ | Psi – 75,000 , MPa -520 | Psi – 30,000 , MPa – 205 | 30 – 35 % |
| Density | 0.287 lb/in3 / 7.94 g/cm3 |
| Melting Point | 2475 – 2525 °F/ 1357 – 1385 °C |
| Specific Heat @ 70°F | 0.11 Btu/lb•°F |
| Permeability @ 70°F Annealed | 1.014 (200 Oersted) |
| Curie Temperature | -115 °C/ -175 °F |
| Elastic Modulus | 28.50 X 106 psi |
| Electrical Resistivity @ 70°F | 595 ohm•circ mil/ft |
| Annealling Incoloy 800 | 983 – 1038 °C / 1800 – 1900 °F |
| Annealling Incoloy 800H / Ht | 1147 – 1177°C / 2100 – 2150 °F |
| Quench | Rapid Air / Water |
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | BS | GOST | OR |
| Incoloy 800HT | N08811 | 1.4959 | – | X8NiCrAlTi32-21 | NCF 800HT | NA 15(HT) | ЭИ670 | XH32T |
To determine if Incoloy 800HT Forgings meet your specific needs, assess their high-temperature resistance, oxidation, and carburization properties against your application requirements. Consulting with a supplier for detailed material specifications and testing options can also ensure compatibility.
The ideal temperature range for forging Incoloy 800HT is between 2100°F (1149°C) and 2300°F (1260°C). This range ensures optimal workability, mechanical properties, and maintains the material's strength and resistance to oxidation.
Temperature control is crucial for maintaining the desired mechanical properties of forged Incoloy 800HT, as overheating or insufficient heating can lead to reduced strength and ductility. Proper temperature management ensures optimal grain structure, resistance to oxidation, and overall performance in high-temperature applications.
These forgings are widely utilized in industrial furnaces, petrochemical processing, heat exchangers, superheater tubes, steam reformers, and various chemical plant equipment. Their ability to resist oxidation, carburization, and harsh chemicals ensures a long service life even in challenging environments. Incoloy 800HT Forgings are particularly prized in the oil & gas, marine, and thermal processing industries for their reliability, durability, and consistent performance under extreme operating conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
