Chuck Metals is a reliable manufacturer and supplier of Stainless Steel 410 Square Bars and Rods right here in Singapore. We pride ourselves on delivering durable, high-performance products to various industries across Pulau Ujong and Southeast Asia. Stainless Steel 410 is a martensitic stainless steel known for its impressive strength, wear resistance, and decent corrosion resistance. Our 410 square bars are crafted in line with ASTM A276 and A479 standards, ensuring they have precise dimensions, a smooth surface finish, and consistent mechanical properties. At Chuck Metals, we offer these bars in a range of sizes and heat-treated conditions, making them perfect for demanding mechanical and structural applications.
These Stainless Steel 410 Square Bars and Rods are made up of 11.5–13.5% chromium and a carefully controlled amount of carbon (around 0.15%), which allows them to be hardened through heat treatment. They boast a tensile strength of 700 MPa, a yield strength between 275–450 MPa, and can achieve excellent hardness of up to 40 HRC when fully hardened. The 410 grade is magnetic, easy to machine, and performs well in mildly corrosive environments like fresh water and air, though it’s not the best choice for marine or highly acidic conditions.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A582, A276, A564, ASTM A484, 484M
Surface : hrap, hot rolled pickled or sand blasting finished, cold drawn, polished, hairline
Size : Tolerance: H8, H9, H10, H11, H12, H13K9, K10, K11, K12
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 410 | 0.15 | 11.5-13.5 | 1.00 | 0.75 | 0.040 | 0.030 | 1.00 |
| Tempering Temperature (°C) | Tensile Strength (MPa) | Yield Strength 0.2% Proof (MPa) | Elongation (% in 50 mm) | Hardness Brinell (HB) | Impact Charpy V (J) |
|---|---|---|---|---|---|
| Annealed * | 480 min | 275 min | 16 min | – | – |
| 204 | 1475 | 1005 | 11 | 400 | 30 |
| 316 | 1470 | 961 | 18 | 400 | 36 |
| 427 | 1340 | 920 | 18.5 | 405 | # |
| 538 | 985 | 730 | 16 | 321 | # |
| 593 | 870 | 675 | 20 | 255 | 39 |
| 650 | 300 | 270 | 29.5 | 225 | 80 |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 410 | 1.4006 | S41000 | SUS 410 | 410S21 | – | – | 56A |
| SQUARES | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.62 | 2.05 |
| 18 | 0.79 | 2.59 |
| 20 | 0.76 | 2.49 |
| 22 | 1.18 | 3.87 |
| 25 | 1.52 | 5.00 |
| 28 | 1.91 | 6.27 |
| 30 | 2.19 | 7.20 |
| 32 | 2.50 | 8.19 |
| 36 | 3.16 | 10.37 |
| 38 | 3.52 | 11.55 |
| 40 | 3.90 | 12.80 |
| 45 | 4.94 | 16.20 |
| 50 | 6.10 | 20.00 |
| 56 | 7.65 | 25.08 |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Yes, Stainless Steel 410 square bars can be welded, but preheating and post-weld heat treatment are often recommended to avoid cracking. Proper welding techniques ensure strong, durable joints.
To ensure the quality of Stainless Steel 410 square bars, source them from reputable suppliers and conduct material testing, such as tensile strength and hardness tests. Additionally, check for proper surface finish and dimensional accuracy.
Yes, we provide 410 Stainless Steel Square Bars and Rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@chuckmetals.com
You’ll find Stainless Steel 410 Square Bars and Rods commonly used in mechanical engineering, automotive, and tooling applications where high strength and wear resistance are crucial. Typical applications include pump shafts, valves, sprockets, gears, and fasteners. In the oil and gas industry, they’re utilized in components that face abrasion and mild corrosion. They’re also great for food processing, machine parts, and construction hardware. Their ability to handle moderate corrosion and high mechanical stress makes them a smart choice for industrial and structural applications that demand durability and performance.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
