Chuck Metals stands out as a top manufacturer and supplier of high-quality Titanium Grade 5 Forgings in Singapore, specifically in Pulau Ujong. Renowned for its precision in manufacturing and unwavering commitment to excellence, Chuck Metals delivers robust, corrosion-resistant forged components for various industries, including aerospace, marine, medical, and chemical processing. Titanium Grade 5 (Ti-6Al-4V) is the go-to titanium alloy, celebrated for its remarkable strength-to-weight ratio and superb corrosion resistance. By employing cutting-edge forging techniques and strict quality control measures, Chuck Metals ensures that its products meet international standards, promising long-lasting performance and reliability even in the toughest conditions.
Titanium Grade 5 Forgings (Ti-6Al-4V) are made up of about 6% Aluminum, 4% Vanadium, 0.25% Iron, and 0.2% Oxygen, with the remainder being Titanium. This alpha-beta alloy boasts impressive tensile strength (usually between 900–1100 MPa), yield strength (around 880 MPa), and hardness reaching up to 36 HRC. It shows excellent fatigue resistance and keeps its mechanical integrity at temperatures as high as 400°C. Lightweight yet incredibly strong, Titanium Grade 5 also offers outstanding corrosion resistance against seawater, oxidizing acids, and chloride environments—making it perfect for high-performance, critical structural and pressure-bearing applications.
| Specifications | ASTM B381, ASME SB381 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade5 | 90 min | – | 0.25 max | – | – | 0.2 max | 6 min | 4 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium Gr. 5 | 4.43 g/cm3 | 1632 °C (2970 °F) | Psi – 138000 , MPa – 950 | Psi – 128000 , MPa – 880 | 14 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 5 | 3.7165 | R56400 |
Titanium Grade 5 Forgings find their place in industries that require high strength, low weight, and exceptional corrosion resistance. In aerospace, they’re used for airframe components, engine parts, and landing gear. The medical sector relies on them for surgical implants and orthopedic devices, thanks to their biocompatibility. In marine and offshore applications, Grade 5 is utilized for propeller shafts, fasteners, and underwater equipment. It also plays a role in automotive performance parts, chemical processing equipment, and power generation components. Its versatility and durability make it a top choice for critical structural and pressure-bearing applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
