Chuck Metals, based in Pulau Ujong, Singapore, stands out as a top manufacturer and supplier of premium stainless steel products, including Stainless Steel 316Ti Forgings. These forgings are celebrated for their remarkable strength and ability to withstand high temperatures and corrosion, making them essential in critical sectors like petrochemical, marine, pharmaceuticals, and power generation. Chuck Metals is committed to ensuring that its 316Ti forgings adhere to international quality standards, delivering reliable performance, precision engineering, and prompt service throughout Singapore and Southeast Asia.
Stainless Steel 316Ti Forgings are a type of titanium-stabilized austenitic stainless steel, featuring a composition of 16–18% chromium, 10–14% nickel, 2–3% molybdenum, and titanium to enhance resistance to intergranular corrosion. This unique blend provides excellent strength and stability, even in high temperatures and corrosive settings. The mechanical properties include a tensile strength of about 75 ksi (515 MPa), yield strength of around 30 ksi (205 MPa), and an elongation rate of 35–40%. The addition of titanium helps prevent carbide precipitation during welding, which boosts structural integrity and durability.
| Standard | ASTM A182, ASME SA182 |
| Specification | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs. |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs. |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs. |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 316Ti | 0.08 max | 2.0 max | 0.75 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 10.00 – 14.00 | 68.395 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1399 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Yes, Stainless Steel 316Ti can be forged into custom shapes. Its excellent formability and resistance to corrosion make it suitable for creating complex designs required in various industries.
Yes, Stainless Steel 316Ti forgings are ideal for structural applications. Their excellent corrosion resistance, high strength, and ability to withstand extreme environments make them suitable for marine, chemical, and architectural structures.
Yes, Stainless Steel 316Ti forgings are ideal for structural applications. Their excellent corrosion resistance, high strength, and ability to withstand extreme environments make them suitable for marine, chemical, and architectural structures.
These Stainless Steel 316Ti Forgings are perfect for high-stress, high-temperature applications, such as heat exchangers, flanges, valve bodies, pressure vessels, and marine components. Their outstanding resistance to oxidation and corrosion makes them particularly suited for aggressive environments, including those with chlorinated and acidic conditions. With superior mechanical properties and dimensional stability, these forgings are vital in industries that require strength, corrosion resistance, and a long service life, even under extreme operating conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
