Chuck Metals stands out as a trusted manufacturer and supplier of top-notch Stainless Steel 420 Hex Bars in Singapore, specifically in Pulau Ujong. With a reputation for precision machining and metallurgical excellence, Chuck Metals caters to various sectors, including tooling, medical, defense, automotive, and industrial engineering. Stainless Steel 420 is a high-carbon martensitic stainless steel celebrated for its remarkable hardness, polishability, and corrosion resistance post-heat treatment. Chuck Metals guarantees that all 420 hex bars are produced to meet international standards, backed by rigorous quality control. Their 420 hexagonal bars deliver outstanding dimensional stability and strength, making them ideal for high-stress, high-wear applications in tough environments.
Stainless Steel 420 (UNS S42000) is composed of about 12–14% Chromium and 0.15–0.40% Carbon, along with trace amounts of Manganese, Silicon, and other elements. It can be heat-treated to achieve a hardness of up to 50 HRC, depending on the carbon content and tempering process. This alloy boasts a tensile strength ranging from 655–860 MPa and offers moderate corrosion resistance when hardened. It’s magnetic and exhibits excellent wear resistance, particularly when hardened and ground. The combination of machinability, polishability, and strength makes 420 perfect for precise, load-bearing applications where both aesthetics and durability are essential.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 420 | 0.15 | 14.0 | 1.00 | – | 0.04 | 0.03 | 1.00 |
| Element | Tensile Strength | Yield Strength | Elongation | Hardness |
| SS 420 | 95,000 | 50,000 | 25 | 175 |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
SS 420 Hex Bars are widely used in applications requiring high strength, hardness and moderate corrosion resistance. Typical applications include the manufacture of molds, surgical instruments, valves, shafts and pump parts. They are also ideal for tools and utensils that resist corrosion of knives, scissors and glass. The materials are used in the automotive, aerospace and aerospace industries for engine parts, gears and fasteners. SS 420 Hex Bars are suitable for corrosion-prone areas, especially in harsh or extreme conditions for excellent performance.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
