Chuck Metals is your go-to manufacturer and supplier of Stainless Steel 15-5 PH Hex Bars and Rods right here in Singapore, Pulau Ujong. They specialize in crafting precision-engineered products that are perfect for high-strength and corrosion-resistant applications. Now, if you’re not familiar, Stainless Steel 15-5 PH (UNS S15500) is a type of precipitation-hardening martensitic stainless steel that boasts fantastic mechanical properties and is easy to work with. Chuck Metals guarantees top-notch 15-5 PH hex bars and rods that adhere to strict industry standards, making them ideal for sectors like aerospace, chemical processing, marine, and various industrial applications. With a strong focus on quality, speedy delivery, and solid technical support, Chuck Metals is a reliable partner for all your high-performance stainless steel needs.
When it comes to composition, Stainless Steel 15-5 PH Hex Bars and Rods typically have around 15% chromium and 5% nickel, along with some copper and carefully controlled amounts of carbon and manganese. This alloy is known for its impressive strength, hardness, and resistance to corrosion after heat treatment. It can achieve a tensile strength between 930 to 1310 MPa and maintains excellent toughness, even when welded. Thanks to its uniform structure, it offers outstanding mechanical properties and dimensional stability, making it a great choice for precision components.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Grade | C | Cb+Ta | Cr | Cu | Fe | Mn | Ni | P | S | Si |
| SS 15-5 PH | 0.07 max | 0.15-0.45 max | 14.0-15.0 max | 2.5-4.5 max | Bal | 1.0 | 3.5-5.5 | 0.04 | 0.03 | 1.0 |
| Grade | Tensile Strength ksi (MPa) | Yield Strength 0.2% ksi (min) | Elongation % | Hardness (Rockwell) MAX |
| SS 15-5 PH | 161,000 | 140,000 | 7.6% | C35 |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 15-5PH | 1.4545 | S15500 |
| HEXAGONS | ||
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Store Stainless Steel 15-5 PH hex bars and rods in a clean, dry, ventilated area, elevated on racks, with protective covers, separated from other metals, and handled carefully.
Stainless Steel 15-5 PH hex bars excel in wear-resistant applications due to their high strength, toughness, excellent corrosion resistance, and ability to maintain hardness after precipitation-hardening heat treatment.
Common challenges with Stainless Steel 15-5 PH hex bars include susceptibility to stress corrosion cracking in chloride environments, limited ductility in hardened conditions, higher machining difficulty, and potential distortion during heat treatment.
You’ll find Stainless Steel 15-5 PH Hex Bars and Rods in a variety of applications, including aerospace structural parts, turbine components, fasteners, shafts, fittings, and high-pressure equipment. They’re also commonly used in marine settings, chemical processing plants, and machinery in the food industry, where both corrosion resistance and high strength are essential. The alloy’s ability to perform well in challenging environments, combined with its good machinability and weldability, makes it perfect for applications that demand reliability, durability, and a long service life.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
