Chuck Metals, based in Pulau Ujong, Singapore, has built a solid reputation as a manufacturer and supplier of top-notch stainless steel products, including Stainless Steel 304L Hex Bars and Rods. These bars are celebrated for their outstanding corrosion resistance, weldability, and versatility, making them a go-to choice in various industries like food processing, marine, pharmaceuticals, and construction. Chuck Metals is committed to delivering consistent product quality, adhering to international standards, and providing reliable customer service, which has made them a trusted source for stainless steel solutions throughout Singapore and Southeast Asia.
Stainless Steel 304L Hex Bar/Rod is a low-carbon variant of the 304 alloy, featuring chromium (18–20%), nickel (8–12%), and a maximum carbon content of 0.03%. This lower carbon content helps reduce the risk of carbide precipitation during welding, enhancing corrosion resistance, particularly in welded structures. In terms of mechanical properties, it boasts a tensile strength of around 70 ksi (485 MPa), a yield strength of about 25 ksi (170 MPa), and an elongation of roughly 40%. The alloy is non-magnetic when annealed and performs admirably in various environments, including mildly corrosive and humid conditions.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 304L | 8.0 – 11.0 | 18.0 – 20.0 | 2.0 max | 8.0 – 12.0 | 0.045 max | 0.03 max | 1.0 max |
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 304L | 8.0 – 11.0 | 18.0 – 20.0 | 2.0 max | 8.0 – 12.0 | 0.045 max | 0.03 max | 1.0 max |
| Element | Density, lb/in3 | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| SS 304L | 8.0 g/cm3 | 1400 °C (2550 °F) | 485 | 170 | 40 |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
SS 304L hex bars/rods are typically available in sizes ranging from 3.17mm to 350mm in diameter, with lengths of 2 to 7.5 meters. These bars come in various finishes, such as polished or cold-drawn. Custom sizes and specifications can also be produced upon request to meet specific needs.
Yes, SS 304L hex bars/rods are highly weldable and suitable for fabrication into complex shapes. Their low carbon content minimizes carbide precipitation during welding, reducing the risk of corrosion. This material's excellent ductility and toughness allow easy forming, machining, and fabrication, making it ideal for intricate designs and applications.
SS 304L has lower carbon content than standard 304, reducing carbide precipitation and enhancing corrosion resistance, particularly after welding. While slightly lower in strength compared to higher-carbon grades like 304 or 316, it maintains excellent toughness and durability. SS 316 offers superior corrosion resistance in chloride environments due to added molybdenum.
Stainless Steel 304L Hex Bars and Rods find applications in structural components, food-grade machinery, chemical equipment, architectural features, and marine hardware. Their hexagonal shape not only improves grip but also facilitates machining, making them ideal for precision parts and fasteners. With their excellent corrosion resistance and polished finish, they are perfect for both sanitary and aesthetic uses. Industries rely on 304L for its durability, low maintenance needs, and superb fabrication qualities in both industrial and commercial applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
