Chuck Metals is a reliable manufacturer and supplier of Aluminium 2014 Forgings based in Singapore, Pulau Ujong. They offer top-notch forged components that meet the rigorous standards of various industries. Aluminium 2014 is a robust alloy celebrated for its outstanding machinability and durability, making it perfect for critical structural applications. At Chuck Metals, every forging is crafted with meticulous attention to detail and consistency, serving sectors like aerospace, automotive, and engineering. With a solid reputation for dependability and a focus on customer service, Chuck Metals has become a go-to source for Aluminium 2014 Forgings, delivering solutions that ensure strength, performance, and longevity.
Aluminium 2014 Forgings primarily consist of aluminium, with copper as the main alloying element (around 3.9–5%), along with trace amounts of silicon, manganese, and magnesium. This unique blend gives the alloy its high strength and impressive fatigue resistance. The mechanical properties boast a tensile strength of about 450–500 MPa and a yield strength ranging from 300–400 MPa, depending on the temper. While it may not be the best at resisting corrosion, its excellent machinability and ability to handle heavy loads make it suitable for heat treatment and demanding mechanical applications.
Standards : ASTM B247, B247
Temper : T6 T651 T6511
Specification : DIN, ASTM, BS and all International Standards
Flat bar blocks : up to 27″ width and 15,000 lbs.
Cylinders and sleeves : up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs : up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings : up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts : up to 144″ maximum length and 20,000 lbs.
| Aluminium 2014 | Fe | Si | Mg | Mn | Cu | Zn | Ti | Al |
| 0.7 | 0.50 – 1.20 | 0.2 – 0.8 | 0.4 – 1.2 | 3.9 – 5.0 | 0.25 | 0.15 | 93.5 |
| Material | Temper | Diameter (mm) | Tensile Strength min ((N/mm²) | Yield Strength (min) (N/mm²) | Elongation on 5.65 V (min) |
| 2014 Bar | T4 | <20 | 370 | 230 | 11 |
| 2014 Bar | T4 | 20-75 | 390 | 250 | 11 |
| 2014 Bar | T4 | 75-150 | 390 | 250 | 9 |
| 2014 Bar | T4 | 150-200 | 370 | 230 | 8 |
| 2014 Bar | T6510 | 20-75 | 480 | 435 | 7 |
| 2014 Bar | T6510 | 75-150 | 465 | 420 | 7 |
| 2014 Bar | T6510 | 150-200 | 435 | 390 | 7 |
| STANDARD | UNS | WERKSTOFF NR. | European Standard | BS (OLD) | ISO | USA (AA) | GERMANY (DIN) | IS | Canadian |
| Aluminium 2014 | A92014 | 3.1255 | EN AW-2014 | HE15 | AlCu4SiMg | 2014 | AlCuSiMn | 24345 | B26S |
Yes, Aluminum 2014 is suitable for high-temperature forging applications due to its excellent strength, thermal resistance, and good machinability, making it ideal for aerospace and automotive components.
Aluminum 2014 offers high strength, excellent machinability, good wear resistance, and superior performance under high-stress conditions, making it ideal for aerospace, automotive, and structural custom forgings.
These forgings find their way into a variety of uses, including aerospace components, truck frames, military vehicles, structural parts, and high-performance engine components, all thanks to their remarkable strength and stress resistance. Their superb machinability allows for the creation of intricate shapes and precise tolerances, making them ideal for heavy-duty engineering projects. Although they aren’t the best choice for marine or highly corrosive environments without a protective coating, Aluminium 2014 Forgings excel in applications where mechanical strength and fatigue resistance are paramount, enhancing structural integrity and ensuring long-term reliability across various industrial settings.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Chuck Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Singapore, Singapore
